HAFE Brand 4T 6T 3wheel Sit-on Towing Tractor With 4t and 6t Capacity
Description
FAAM Battery,Roof,Warning Alarm;
Warranty
1). 12 month for frame,pump,controller,motor with right operation; 2). 12 months for battery and changer;
2). easy-broken items not in our responsibility,like wheel,bearing,carbon brush, friction disk,ignition switch,wire,plastic parts etc;
1. very easy to operate.
2. it is still equipped with high-power and high-performance .
3. The long handle meets the ergonomics principle and is comfortable to operate.
4. Side-driven design effectively reduces the size of operation channel. With small turning radius and better view, this stacker is suitable for narrow spaces.
5. Power outage and brake function. When the handle is released or pressed to the bottom, the truck will be power outage and brake immediately. When the truck is out of control or on the ramp,
this feature is particularly useful, which makes the truck more secure.
6. Installation of high-density wire fence. It is strong and durable, with good protection effect.
Our Services
Pre-Sales Service
* Inquiry and consulting support.
* Photos&Videos for your order before shipment.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Whole life-time supply for spareparts.
The following items are optional:
Tires: Pneumatic and Solid tire
Color: Yellow,red,orange, green, blue or customized.
Engine:subishi/Xinchai/Xinchang/Volvo/Isuzu/Perkins/Cummins engine are optional.
Mast: Standard wide-view 2 stage mast, wide-view 2-stage full free mast, wide-view 3-stage full free mast.
Power source: Diesel,Gasoline,LPG,CNG,AC/DC electric forklift are available.
Parameters
| | | TG40 | TG60 |
| Standard | Power Type | | Battery | Battery |
| Operate Type | | Seated | Seated |
| Rated Capacity | Q(kg) | 4000 | 6000 |
| Rated Drawbar Pull | F(N) | 800 | 1200 |
| wheel base | y(mm) | 1040 | 1040 |
| Weight | Service Weight | kg | 920 | 1000 |
| Axle load without load,front/rear | kg | 365/555 | 410/590 |
| Tyre | Wheel Type-Front/Rear | | Solid rubber / Penumatic Rubber |
| Front Wheel | | 4.00-8 | 4.00-8 |
| Rear Wheel | | 4.00-8/6PR | 4.00-8/6PR |
| Tyres No. -front/rear (X=Drive wheel) | | 1 / 2X | 1 / 2X |
| Tread Front/rear | b2(mm) | 0/870 | 0/870 |
Dimen
sion | Overall Height incl. cab | h5(mm) | 2045 | 2045 |
| Height of seat | h3(mm) | 895 | 895 |
| Height of coupler center (from floor) | h1(mm) | 210/275/340/405 | 210/275/340/405 |
| Hiehgt of platform,wothout load | h2(mm) | 610 | 610 |
| Length of loading platform | b3(mm) | 790 | 790 |
| Rear Overhang | L2(mm) | 405 | 405 |
| Width of Loading platform | L3(mm) | 390 | 390 |
| Overall Length | L1(mm) | 1790 | 1790 |
| Overall Width | b1(mm) | 990 | 990 |
| Min. Ground Clearance | m(mm) | 140 | 140 |
| Trurning radius | Wa(mm) | 1650 | 1650 |
| Min. pivoting point distance | b4(mm) | 600 | 600 |
Func
tion | Travel Speed -without load | km/h | 8/14 | 7/17 |
| Max. Traction (S2 5) | N | 3800 | 4500 |
| Max. Gradeability -laden/unladen | % | see the graph |
| Driving Motor (S2 60) | kw | 3 | 4.5 |
| Battery voltage /rated capacity(5h) | V/AH | 24/490 | 48/280 |
| Battery weight | kg | 390 | 475 |
| Option-battery power | AH | 280,350 | 350 |
| Drive control type | | electricnic /stepless |
| Noise level | dB | 66 | 66 |
| Other | | | | |
